UNI-T Unit Thermal Imager UTi165A Temperature Thermal Imaging Camera Industry Temperature Tester

  • UNI-T Unit Thermal Imager UTi165A Temperature Thermal Imaging Camera Industry Temperature Tester
  • UNI-T Unit Thermal Imager UTi165A Temperature Thermal Imaging Camera Industry Temperature Tester
  • UNI-T Unit Thermal Imager UTi165A Temperature Thermal Imaging Camera Industry Temperature Tester
  • UNI-T Unit Thermal Imager UTi165A Temperature Thermal Imaging Camera Industry Temperature Tester
Luogo di origine Cina
Marca uni-t
Certificazione /
Numero di modello UTi165A
Quantità di ordine minimo 1 pz
Prezzo USD 160/PC
Imballaggi particolari Imballaggio originale
Tempi di consegna 1-3 giorni lavorativi
Termini di pagamento T/T
Capacità di alimentazione 1000pc/mese

Contattimi gratis campioni e buoni.

whatsapp:0086 18588475571

Wechat: 0086 18588475571

Skype: sales10@aixton.com

Se avete di preoccupazione, forniamo la guida in linea di 24 ore.

x
Dettagli
Risoluzione IR (pixel) 160×120 Display LCD TFT da 2,8” (320×240)
Campo visivo 56°×42° Messa a fuoco Concentrati liberamente
Intervallo di misurazione della temperatura -10℃~400℃
Lasciate un messaggio
Descrizione di prodotto

Heavy Duty Thermal Camera

UTi165A is a rugged and ergonomically designed thermal camera, powerful and user friendly with great performance, with 160×120 pixels IR resolution which can automatically track the objective’s temperature from -10℃~400℃. It is an affordable professional troubleshooting tool, widely used in many applications.

Features :

  • Durable and user-friendly
  • 8” TFT display screen (320×240 Pixels)
  • IR resolution: 160×120
  • Temperature measurement range: -10℃ to 400℃ / 14℉ to 752 ℉
  • Auto alarm for high/low temperature
  • Auto tracking for hot spot/cold spot
  • Image capture
  • Color palettes: 5(White hot, Red hot, Ice blue, Rainbow, Ironbow)
  • LED flashlight
  • PC software analysis
  • Rechargeable Li-ion battery
  • 1/4” tripod mounting hole
  • IP65
  • 2m drop proof



Product Specifications of UTi165A

Technical Data
IR resolution (Pixels) 160×120
Display 2.8” TFT LCD (320×240)
Field of view(FOV) 56°×42°
Thermal sensitivity(NETD) ≤50mk
Spatial resolution(IFOV) 6.1mrad
Frame rate ≤9Hz
Spectral range 8~14µm
Focus Focus free
Temperature measurement range -10℃~400℃
Accuracy ±2℃ or ±2% whichever is greater
Emissivity 0.01~1.00 adjustable (0.95 default)
Functions
Color palettes 5
(White hot, Red hot, Ice blue, Rainbow, Ironbow)
Image modes Thermal
Hi/Lo temperature alarm Icon,LED flashlight
PC software analysis √
General Characteristics
Battery Fixed Li-ion battery (3.6V 5000mAh)
Battery operation time ≥ 6 hours
USB Type-C
IP rating IP65
Drop proof 2m
Storage Up to 32GB Micro SD card
Image/Video storage format BMP
Certificates CE,FCC,RoHS
Product net weight 490g
Product size 236mm×75.5mm×86mm



Applications of UTi165A

PCBA inspection, motor inspection, automotive maintenance, solar panel inspection, power distribution cabinet inspection, electricity facilities inspection, mechanical equipment inspection, heating equipment inspection, building&HVAC inspection etc.
